Volkswagen Crafter (LT3)

The Volkswagen Crafter 2EFI Series is built in the Mercedes-Benz Ludwigsfelde, German factory which also builds the Mercedes Sprinter NCV3 Series. During the 1990's Volkswagen and Mercedes entered into a commercial arrangement where the Crafter and the Sprinter share the same body shell. In the Volkswagen Crafter the engine and transmission remain Volkswagen sourced.
A very popular vehicle for motorhome conversion in Europe the reliable and durable Volkswagen Crafter was released in Australia in 2007.
Products available for the Volkswagen Crafter follow:
Insect Screens for Window Openings:
The Flexible Magnetic Insect Screen for the passengers and drivers door window openings attaches externally to the ferrous metal body panels that surround the window frames. The factory fitted sliding window requires a sub frame that permanently attaches externally to the glass surrounding the slide in glass pane to provide a ferrous surface on which to magnetically attach the insect screen.
Flexible Magnetic Insect Screens installed on the passenger and drivers door window openings used in combination with the tailgate insect screen provides for maximum flow through ventilation. Flexible Magnetic Insect Screens installed on the passenger and drivers door window openings where the passenger and/or drivers seats can be rotated 180 degrees also provides for fresh air induction directly adjacent to your seating position.
The Flexible Magnetic Insect Screen rolls up for storage in a tube or optionally can be stored flat.
Flexible Magnetic Insect Screening products are available to screen the following windows:
1. Passenger Door Window Opening for EXTERNAL installation where weather shields are not installed.
2. Drivers Door Window Opening for EXTERNAL installation where weather shields are not installed.
3. Factory fitted Sliding Window Opening.
4. Any other aftermarket window opening (dimensions of window need to be confirmed prior to insect screen manufacture).
Insect Screen for Sliding Door Opening:
The Sliding Door Opening is nominally 130cm wide by 172cm high.
The Flexible Magnetic Insect Screen component is comprised of two overlapping mesh panels, or optionally three overlapping mesh panels secured internally in a track at the top of the door opening. Flexible magnet provides the seal down each side of the opening and between the overlapping mesh panels. The bottom seal is also provided by a flexible magnetic fastener.
Entry into and exit out of the vehicle is simply a matter of pushing against the mesh to break the magnetic seal and then moving through the overlapping mesh panels.
When insects are not an issue for the two overlapping panel version one half of the width of the insect screen can be slid out of the track and folded back and secured against the other half of the screen to provide one half of the door opening with an unobstructed thoroughfare; with the three overlapping panel version the centre panel can be rolled up and secured at the head of the door opening with the ties provided.
The sliding door insect screen can be totally removed in around 10 to 15 seconds for cleaning and is just as easy to reinstall. When the sliding door insect screen is not required it can be easily removed for storage using the optional storage hanger.
The Sliding Door Flexible Magnetic Insect Screen is a robust product that provides an effective barrier against insect entry.
Insect Screen for Tailgate Opening:
A Flexible Magnetic Insect Screen for the tailgate opening provides an effective insect screening barrier to an opening nominally 1565mm wide x 1790mm high.
A Flexible Magnetic Insect Screen for the tailgate opening is comprised of three overlapping mesh fabric panels secured internally at the head of the door opening in a track. The seal for the left and right side vertical perimeters is also provided by a fixed tracking system.
The seal between the overlapping mesh panels is provided by a two part flexible magnetic fastener that runs the full height of the tailgate opening. The bottom seal is provided in part by hook and loop fastener and in part by a flexible magnetic fastener.
The centre panel of the tailgate insect screen can be rolled up out of the way and held in place with two ties that are attached to the top of the insect screen assembly.
The tailgate opening Flexible Magnetic Insect Screen can be easily removed for cleaning and/or storage and reinstalled by sliding the insect screens perimeter into the fixed tracking system.
Entry into and out of your vehicle is simply a matter of moving through the centre overlapping mesh panel. The product is robust and provides an effective barrier against insect entry.
Sun Shields for Thermal Protection and Privacy:
Sun Shields are available for internal installation to the windscreen only, or optionally, as a cabin set (includes the windscreen and also the passenger and drivers door windows).
Sun shields can also be made for any other window or hatch in your vehicle.
Lightweight Awning for Rear of Vehicle:
A lightweight awning that provides protection to the rear of the vehicle between the rear barn doors further contributes to the comfort of your motorhome.
 The side perimeters of the awning slides into a track system that is attached internally to each of the upper door panels whilst the rear of the awning attaches to the underside of the rear door opening. The lightweight awning provides shade to the rear of the vehicle and prevents rain from entering the rear opening of the motorhome.
The rear awning is an excellent accessory to maximise the benefits of the tailgate opening insect screen.
